EMC Partner MIL-MG3 Rental System Overview

EMC Partner MIL-MG3

Name: EMC Partner MIL-MG3 - Rent MIL-STD & DO-160 Test System
Brand: EMC Partner
Availability: InStock

Rent MIL-STD & DO-160 Test System

In Stock & Ready To Ship

Orders by 3pm ship today

The EMC Partner MIL-MG3 is a modular transient generator for MIL-STD-461 CS115 and CS116 testing, offering automated routines, multiple damped-sine frequencies, and compatibility with the CN-BT6 injection probe.

Features

Exceeds maximum test levels in MIL-STD-461

Single Generator for CS115 & CS116 Requirements

Automated Test Routines from Front Panel

Includes CN-BT6 Injection Probe

Current ISO 17025 Accredited Calibration

Up to 4 Free Days of Transit Time

Two transit days each way are excluded from rental period

Included Modules Configured on this product

MIL3-REC

MIL3-10K10M

MIL3-30M100M

MIL-MG3 & Power Cord

Pearson 8705C

MIG Aux Keeper

Printed Manual & Documentation

50 Ohm N Termination

MIL3-10K10M

MIL3-30M100M

MIL3-REC

20dB 10kHz & 100kHz Attenuators

CN-BT6

VERI-MIL3 & VERI-MIL

2 pcs 20 dB BNC & 2 pcs N Attenuators

N to BNC Cable

SHV 50 Ohm Termination

3 pcs MC to MC Cables

1 & 2 Meter SHV to SHV Cables

EMC Partner MIL-MG3 Test system and associated accessories with the rental

Can't find something? Contact Us

Description

Portable multifunction impulse test generator with plug-ins for MIL-STD and DO-160 applications. Test capability is easily extended with the seven plug-in modules. Couplers and calibration accessories complete the solution.

A versatile, flexible system that uses modules to provide a wide variety of impulse types for many applications. All versions of MIL-STD-461 impulse test requirements are available, including CS06, CS106, CS115 and CS116. Additional modules are available for DO-160 section 17 and 19 applications. A full range of test and calibration accessories compliment this practical solution. A colour touch panel assists with test programming through the use of graphic help functions. The integrated web server makes it easy to view test report data in any internet browser.

MIL-MG3

MIL-MG3 system comprises a base unit with user changeable impulse modules. A coupling transformer, for cable injection tests, completes the system. The 7 inch graphic colour touch panel provides an intuitive and comfortable user interface.
Interactive parameter input, help text and graphic illustrations guide the user through the instrument programming process.

Modules

Modules are available for MIL-MG3 system to cover different test requirements. Users can select a module for an individual test and add additional modules to enhance the test system capability. New modules are automatically recognized and controlled by the MIL-MG3 base unit. All modules are independent and can be ordered at any time.

CN-BT6

Injection probe for CS115 and also CS116. A single coupler that covers the complete frequency range 10 kHz up to 100 MHz. Aperture 5 cm for large cable bundles.

MIL-MG3 Specifications
Input Power
Voltage: 100 V - 240 V +/- 10 %
Frequency: 50 Hz - 60 Hz
Consumption
Switched off: 0 VA
Standby: <15 VA
Test running: max. 150 VA
Dimensions: 57 cm x 45 cm x 19 cm
Weight: 17 kg
Environmental Conditions
Temperature: 10 C - 35 C
Humidity: <80 % non condensing
Pressure: 86 kPa - 106kPa
System
Display: 7 Inch Capacitive Touch
Internal memory: 1 GB RAM
4 GB Flash
Connections
USB: 2 * Typ A Plug
LAN: RJ45
Gigabit Ethernet
Trigger Output: BNC max. 6 V
Control Ports: 2 x RS485
Auxiliary Connector: Safety Circuit
Warning Lamps (24 V / max. 2.4 W)
Emergency Stop
Multi Purpose Connection
Frontpanel: 4 * BNC
Rearpanel: 2 * BNC
Programmable Inputs: Trigger Input
Start Test
Stop Test
EUT Fail
EUT Mark
Emergency Stop
Input Low Voltage: < 1.5 V
Input High Voltage: > 2.3 V
Max. Input Voltage: 24 V
Programmable Outputs: Running State
Safety Circuit State
Max. Output Voltage: 24 V
Max. Output Current: 300 mA

MIL3-REC Specifications
Standard: MIL-STD-461 G CS115
Current into 100 Ohms: 1 A - 10 A +/- 10 %
Rise time: <2 ns
Fall time: <2 ns
Duration: >=30 ns

Repetition: 0.03 s - 60 s
Polarity: positive, negative
Coupling: CN-BT6
max. EUT Current: unlimited
Dimensions: 45 cm x 21 cm x 9 cm
Weight: 2 kg

MIL3-10K10M Specifications
Standard: MIL-STD-461 G CS116
Frequency: 10 kHz +/-10 %
100 kHz +/-10 %
1 MHz +/-10 %
10 MHz +/-10 %
Current into 100 Ohms
10 kHz: 20 mA - 220 mA +/-10 %
100 kHz: 0.2 A - 2 A +/-10 %
1 MHz: 1 A - 12 A +/-10 %
10 MHz: 2 A - 12 A +/-10 %
Damping factor: 15 +/-5
Repetition: 0.5 s - 60 s
Polarity: positive, negative
Coupling: CN-BT6
max. EUT Current
50 Hz: 160 Amps
400 Hz: 20 Amps
800 Hz: 10 Amps
Dimensions: 45 cm x 21 cm x 9 cm
Weight: 3.5 kg

MIL3-30M100M Specifications
Standard: MIL-STD-461 G CS116
Frequency: 30 MHz +/-10 %
100 MHz +/-10 %
Current into 100 Ohms
30 MHz: 2 A - 12 A +/-10 %
100 MHz: 1 A - 6 A +/-10 %
Damping factor: 15 +/-5
Repetition: 0.5 s - 60 s
Polarity: positive, negative
Coupling: CN-BT6
max. EUT Current
50 Hz: 320 A
400 Hz: 40 A
800 Hz: 20 A
Dimensions: 45 cm x 21 cm x 9 cm
Weight: 2 kg

EMC Partner Military Test System Brochure

Download

EMC Partner MIL-MGS3 User Manual

Download

1 file

EMC Partner MIL Test Setups

FAQs

This rental configuration supports MIL-STD-461 CS115 bulk cable injection pulse testing and CS116 damped sinusoidal transient testing.

The system includes the MIL3-REC module for CS115 and the MIL3-10K10M and MIL3-30M100M modules for CS116 testing.

The included modules generate the six standard CS116 frequencies: 10 kHz, 100 kHz, 1 MHz, 10 MHz, 30 MHz, and 100 MHz.

The MIL3-REC module produces adjustable 1 to 10 A pulses into 100 ohms with rise and fall times below 2 ns and a pulse duration of at least 30 ns.

Yes. The CN-BT6 injection probe is included and supports CS115 and CS116 testing across the complete 10 kHz to 100 MHz CS116 frequency range. Its 5 cm aperture accommodates large cable bundles.
